Logging test results with NUnit

February 28, 2015 | tags: unit-testing nunit extensions logging design

Recently, a question popped at StackOverflow asking what needed to be done in order to custom-log unit test failures. Not many people know that, but NUnit offers extensions API which could be utilized to solve this very problem. In this post, we’ll see how.

NUnit Addins API

To extend NUnit we need to implement an addin listening to events NUnit triggers during different stages of tests execution. Our response to such events (preferably test finished event) will be logging some data to a file. As simple as that. Let’s see what do we got:

  • IAddin interface & NUnitAddinAttribute – these two will be used to “introduce” our addin to NUnit and make sure it is loaded and present during tests execution
  • EventListener – this interface (yes, an interface) will be our primary implementation doing actual logging when some test-related event occurs

All the components we need are available as NUnit.AddinsDependencies package, available on NuGet.

NUnitFileLoggerAddin

1. Detection

In order for NUnit to detect our addin we need to mark class implementing it with NUnitAddinAttribute and implement IAddin interface:

[NUnitAddin(
  Name = "File Logger",
  Description = "Writes test result to file",
  Type = ExtensionType.Core)]
public partial class NUnitFileLoggerAddin : IAddin

We’ll also kick off unit tests project with the very first test verifying whether our addin is discoverable. With FluentAssertions, it is as easy as:

[Test]
public void NUnitFileLoggingAddin_IsDiscoverable()
{
    var addin = new NUnitFileLoggingAddin();

    addin.Should().BeAssignableTo<IAddin>();
    addin.GetType().Should().BeDecoratedWith<NUnitAddinAttribute>(
        a => a.Type == ExtensionType.Core);
}

2. Installation

Next, the addin must hook itself to NUnit’s extensions system via IAddin.Install method:

public bool Install(IExtensionHost host)
{
  var listeners = host.GetExtensionPoint("EventListeners");
  if (listeners == null)
    return false;

  listeners.Install(this);
  return true;
}

This is to make sure we receive notifications when test-related event occurs.

3. EventListener interface

This interface offers notifications for various stages of test suite execution. The one that we want to hook to is TestFinished method. We’ll simply log time, result and test name. If a test fails, we also save an error message:

public void TestFinished(TestResult result)
{
    using (var file = File.Open("Log.txt", FileMode.Append))
    using (var writer = new StreamWriter(file))
    {
        var message = string.Format("[{0:s}] [{1}] {2}", DateTime.Now,
            result.ResultState, result.Name);
        writer.WriteLine(message);
        var isFailure =
            result.ResultState == ResultState.Error ||
            result.ResultState == ResultState.Failure;
        if (isFailure)
        {
            writer.WriteLine(result.Message);
        }
    }
}

That’s all you need to log test results to custom file. Simply copy NUnitFileLoggingAddin class files to your test project and your tests will be logged to Log.txt file. However, we are far from done.

Design considerations

In its current form our addin is rather poor piece of software. We lack proper unit tests (File.Open and DateTime.Now sort of get in the way) and even changing log file name would require recompilation. This is no good.

Before we jump straight to refactoring let’s take a moment to think about possible improvements and extension points of our addin.

1. Code quality improvements

  • We should have unit tests for logging part. This requires abstracting file access and time.
  • NUnit will not allow us to inject abstracted dependencies via constructor arguments (addin instances are created via reflection). We need to find a way around it.
  • NUnit will not allow to have addin in separate assembly (it must be in the same one as our tests)1. We want to have majority of features in a base class, so that all is required is creating derived type in our test assembly.
  • (optional) Opening a file for writing with each test execution is not very efficient thing to do. We’d be better storing results and writing them all at once.

2. Extensibility

  • It would be good if we could change log file name/location.
  • …or log message format.
  • (optional) Instead of to a file, maybe we could write test results to a database or a web service.

Refactoring for testability and extensibility

Our first step would be to introduce abstractions over file system and time, IFileStreamFactory and ITimeProvider, respectively. Now, we also need to solve the problem with providing those abstractions. Since NUnit will create addin instance using reflection, there should be working parameterless constructor for our addin. Yet we also need constructor with parameters to pass mocked dependencies in unit test. What do we do? We use an anti-pattern – poor man’s DI:

public NUnitFileLoggingAddin()
    : this(new FileStreamFactory(), new TimeProvider())
{
}

public NUnitFileLoggingAddin(
    IFileStreamFactory fileStreamFactory,
    ITimeProvider timeProvider)
{
    this.fileStreamFactory = fileStreamFactory;
    this.timeProvider = timeProvider;
}

We’re good to write few tests for the logging part. As you might know from my previous posts, unit testing, IDisposable and Stream don’t play along very well. To test I/O interactions we will be using StreamRecorder class:

[Test]
public void TestFinished_LogsSuccessfulTestNameAndTimestampToFile()
{
    var testResult = CreateTestResult("DummyTestName",
        ResultState.Success);
    var streamRecorder = new StreamRecorder();
    A.CallTo(() => fileStreamFactory.Create(A<string>._, A<FileMode>._))
        .Returns(streamRecorder.UnderlyingStream);
    A.CallTo(() => timeProvider.Now())
        .Returns(10.May(2015).At(17, 35, 20));

    addin.TestFinished(testResult);

    streamRecorder.WrittenContent.Should()
        .StartWith("[2015-05-10T17:35:20] [Success] DummyTestName")
}

Test above simply verifies whether correct message is written to log file. We should add couple more tests for logging functionality before we proceed to extensibility refactoring. All unit tests written for NUnitFileLoggerAddin can be viewed at my GitHub repository.

Extension points

At this point our addin is fully usable. We might even use it to record its own tests - all we need is a local type inheriting from our base NUnitFileLoggerAddin class:

[NUnitAddin] public class LoggerAddin : NUnitFileLoggerAddin { }

This is a minor nuance given how we want to have our addin reusable, but luckily majority of the features can remain in base class.

Back to extension points. As I mentioned, we want to have control over the output formatting and log file path. To achieve this, our base NUnitFileLoggerAddin will expose several protected virtual members:

protected virtual string LogFilePath { get { return "Log.txt"; } }
protected virtual string CreatePassedTestMessage(TestResult result,
    DateTime currentTime)
protected virtual string CreateFailedTestMessage(TestResult result,
    DateTime currentTime)

Now, our LoggerAddin can for example change the way failed tests are reported:

[NUnitAddin]
public class LoggerAddin : NUnitFileLoggerAddin
{
    protected override string CreateFailedTestMessage(TestResult result,
        DateTime currentTime)
    {
        return string.Format("{0} failed. Investigate!", result.Name);
    }
}

Conclusion

Although we only did simple logging, available API offers much more in terms of extensibility. For example, similar mechanism can be used to write database integration testing API where NUnit will gather all tests marked with special database attribute, and before any of them is run, it will execute some code, for example creating database and inserting test data. We’ll explore these options in the next blog post.

It is also worth noting that upcoming NUnit 3.0 will replace the way how addins are implemented. Read about it at NUnit Addins wiki page and Addins replacement in (NUnit) Framework.

How to mock private method – solutions

January 25, 2015 | tags: unit-testing mocking c# design

I one of my previous blog entries I explained why it is not possible to mock private methods with tools like Moq or FakeItEasy. In this post I’ll show how you can overcome such situation1.

Problem: Origins

First, it is important to identify source of the problem. When you say

I need to mock this private method

All I can hear is

This class is poorly designed. I must use some workarounds or even ugly hacks in order to test it. I know I shouldn’t be going down that road, but it seems I have no choice.

Properly designed SOLID code will never put you in a position which will require you to do private mocking. Source of the problem? Bad design.

To better understand my point let’s take a quick look at a class building order XML. Suppose you want to test CreateDocument method:

public class OrderDocumentFactory
{
    public XDocument CreateDocument(Order order)
    {
        var document = new XDocument();
        document.Add(new XElement("Order",
            new XElement("Date", order.Date.ToShortDateString()),
            new XElement("OriginalValue", order.TotalValue),
            new XElement("Discount", CalculateDiscount(order))
        ));

        return document;
    }

    private double CalculateDiscount(Order order)
    {
        var promotionsFileName = string.Format("P_{0:ddMMyy}.TXT",
            order.Date);
        var promotionsFileContent = File.ReadAllText(promotionsFileName);
        var baseDiscount = double.Parse(promotionsFileContent);
        var isLateProcessing = (DateTime.Now - order.Date).TotalDays > 3;
        var bonusDiscount = isLateProcessing ? 10.0 : 0.0;
        var totalDiscount = baseDiscount + bonusDiscount;

        return order.TotalValue * (100 - totalDiscount) / 100.0;
    }
}

CreateDocument is trivial to test if we can mock this discount calculation thing. With all the file-loading, date-parsing and what-not, it simply gets in our way. This is a lot of stuff we do not really care about, we should mock it. But we cannot. What to do then?

Design considerations

Single responsibility principle, first of the SOLID principles states that:

Every class should have a single responsibility (a reason to change - JK), and that responsibility should be entirely encapsulated by the class

In other words, class should do one thing and one thing only. OrderDocumentFactory, what does it do? It builds XML. If our requirements evolved so that we need to return slightly different XML, that is our one reason to change the class in question. Building XML is our single responsibility.

Unfortunately, OrderDocumentFactory also has second, hidden responsibility – it calculates discount. Had we decided bonus discount is no longer supported, we’ll have to modify OrderDocumentFactory class. This is strange because why would document factory had anything to do with discount calculation? If we wanted to change discount calculation logic we should be rather looking to modify DiscountCalculator class. And there goes our problem – we have one class pretending to be two2.

SOLID solution

We already know what to do. We need a second class that will handle discount calculation logic. All right then, is this code unit testable now?

public XDocument CreateDocument(Order order)
{
    var document = new XDocument();
    var discount = new DiscountCalculator().CalculateDiscount(order);
    document.Add(new XElement("Order",
        new XElement("Date", order.Date.ToShortDateString()),
        new XElement("OriginalValue", order.TotalValue),
        new XElement("Discount", discount)
    ));

    return document;
}

Not so fast. This “solution” adds another responsibility to CreateDocument method – instance creation. We do not want that. What if DiscountCalculator required some constructor arguments? Where would CreateDocument take them from? Instance creation is almost always out of scope of any class responsibilities. We need dependency injection:

public class OrderDocumentFactory
{
    public OrderDocumentFactory(IDiscountCalculator discountCalculator)
    {
        this.discountCalculator = discountCalculator;
    }

    public XDocument CreateDocument(Order order)
    {
        var document = new XDocument();
        var discount = discountCalculator.CalculateDiscount(order);
        document.Add(new XElement("Order",
            new XElement("Date", order.Date.ToShortDateString()),
            new XElement("OriginalValue", order.TotalValue),
            new XElement("Discount", discount)
        ));

      return document;
    }

    private readonly IDiscountCalculator discountCalculator;
}

With code structured like this you don’t have to mock private method but instead you mock dependency, IDiscountCalculator, which is the usual course of action.

Conclusion

In most of the cases the need to mock private method originates from poor design. Design that is already causing problems (inability to write unit tests) and will cause more problems as the code grows. Solution is simple:

  • Fix your design by sticking to SOLID principles
  • Class should do one thing and one thing only; the fact that you need to mock private method of your class usually indicates there is a second class with different responsibility hiding there
  • Any additional responsibilities should be extracted as separate components and provided to class in question via dependency injection

Unit tests are much like your good buddy. When dealing with your code they will be first to ask “Wait a second, this cannot be right?”. Mocking private method cannot be right. And it is not.

  1. We have to make important assumption here - you can change problematic code.

  2. Private CreateDiscount method is a class in disguise.

Comparing lists with NUnit – the definite guide

January 02, 2015 | tags: c# unit-testing nunit list

Very often you’ll run into situation where in your unit test you have to compare two lists against each other. In this post I show several ways to do that, describe common pitfalls and nuances.

Simple types with Assert.AreEqual

When our list contains “simple type”1 like int or string assertion is rather straightforward. There is plethora of different methods we could use but for now NUnit’s Assert.AreEqual should be enough:

[Test]
public void SimpeTypes_Integer()
{
    var expected = new List<int> { 1, 2, 5 };
    var actual = new List<int> { 1, 2, 5 };

    CollectionAssert.AreEqual(expected, actual); // collections specific
    Assert.AreEqual(expected, actual);           // classic model
    Assert.That(actual, Is.EqualTo(expected));   // constraint model
}

NUnit will then use its custom EnumerablesEqual to verify whether each element of actual has its corresponding element in expected (note that both lists have to be in the same order). Comparison of individual elements will default to Equals call.

In case order of elements is irrelevant we’ll have to use Equivalent comparison instead:

[Test]
public void SimpleTypes_IntNotInOrder()
{
    var expected = new List<int> { 1, 2, 5 };
    var actual = new List<int> { 1, 5, 2 };

    CollectionAssert.AreEquivalent(expected, actual);
    Assert.That(actual, Is.EquivalentTo(expected));
}

Custom types

Problems arise when we have to compare collections that contain our custom-defined types. Consider this naive Quotation type which stores information about stock closing price:

public class Quotation
{
    public string Ticker { get; set; }
    public DateTime Date { get; set; }
    public decimal Close { get; set; }
}

The following test will naturally fail as we know even though compared quotations are semantically the same, they are in fact, different instances:

[Test]
public void CustomTypes_Quotation()
{
    var expected = CreateQuotations().ToList();
    var actual = CreateQuotations().ToList();

    Assert.AreEqual(expected, actual);
    Assert.That(expected, Is.EqualTo(actual));
}

private IEnumerable<Quotation> CreateQuotations()
{
    var date = new DateTime(2014, 07, 31);
    yield return new Quotation { Ticker = "APPL", Close = 110.38m, Date = date };
    yield return new Quotation { Ticker = "MSFT", Close =  46.45m, Date = date };
}

This is easily fixable though. Remember how I mentioned NUnit will default to using Equals in individual objects comparisons? All we have to do is provide one. Or do we? There are few issues with such approach:

  • To do it correctly, we’ll have to implement not only Equals but also GetHashCode (which has nothing to do with our original problem).
  • It forces us to extend our custom class with test-only implementation. While it is true that unit tests will often drive design of our code, the changes should come from how our code is used, not from testing frameworks limitations.

Since there doesn’t seem to be any better way to do this2, for now we’ll implement Equals to make the test pass.

Problem with reference types

What about types we cannot override Equals? Like XElement? We could project our collection to bit more representable form:

[Test]
public void ReferenceTypes_XElement()
{
    var list = new List<XElement> { new XElement("a"), new XElement("b") };
    var expected = list.Select(x => x.ToString()).ToList();
    var actual = list.Select(x => x.ToString()).ToList();

    CollectionAssert.AreEqual(expected, actual);
    Assert.AreEqual(expected, actual);
    Assert.That(expected, Is.EqualTo(actual));
}

This works but you can probably already see problems with such approaches – we have to add methods we don’t really need (Equals), use methods that were not meant to be used this way (ToString) or resort to overly complex solutions. It looks very clumsy. We need to find a better way.

Enter FluentAssertions

Just like virtually any problem you might ever encounter this one has, too, already been solved. FluentAssertions is a library that contains a set of extensions to make asserts more fluent (name kind of spoiled it). On top of really good API and clear error messages it provides solutions for common assertions problems, like the one we are facing here.

The ShouldBeEquivalentTo extension method is what we are looking for. It is a smart method that will compare entire objects graph and apply appropriate strategy depending on underlying types. In our case, the actual XMLs will be compared (or to be more specific, properties of XElement that are relevant to XML semantics). This makes our test look like this:

[Test]
public void ReferenceTypes_XElement()
{
    var expected = new List<XElement> { new XElement("a"), new XElement("b") };
    var actual = new List<XElement> { new XElement("b"), new XElement("a") };

    actual.ShouldBeEquivalentTo(expected);
}

You might have noticed I changed the order of elements in actual and expected lists. By default ShouldBeEquivalentTo performs orderless comparison (same as NUnit’s Is.EquivalentTo). Changing this behavior is as easy as this:

[Test]
public void ReferenceTypes_XElementOrderMatters()
{
    var expected = new List<XElement> { new XElement("a"), new XElement("b") };
    var actual = new List<XElement> { new XElement("a"), new XElement("b") };

    actual.ShouldBeEquivalentTo(
        expected,
        options => options.WithStrictOrdering()
    );
}

In case order is different we’ll get helpful message explaining what’s going on:

Expected item[0].Name.LocalName to be “a”, but “b” differs near “b” (index 0).
Expected item[1].Name.LocalName to be “b”, but “a” differs near “a” (index 0).

We can also get rid of Equals method on our Quotation class. ShouldBeEquivalentTo will compare type’s public properties against each other to a decent depth level – they don’t even have to be the same type (all of this is highly configurable).

ShouldBeEquivalentTo is just one of multitude of methods and approaches you can use. For collections alone there’s 20+ custom methods. Resulting assertions are fluent. I bet you know exactly what’s going on in the following snippet without a word of explanation:

actual
  .Should()
  .HaveCount(2).And
  .OnlyContain(q => q.Date == 31.July(2014)).And
  .ContainSingle(q => q.Ticker == "MSFT");

Notice the 31.July(2014). It is FluentAssertions’s fluent API for date & time.

Conclusion

I barely scratched the surface of FluentAssertions. It supports many different types, has excellent extensibility options, is highly configurable, produces meaningful error messages and very readable unit tests code. Go discover it all yourself. Forget about NUnit’s Assert. Even though it is good API, FluentAssertions is simply vastly superior. Once you’ll start using it you will never go back.

The definite guide contains single rule – start using FluentAssertions.

  1. By “simple type” I mean catch-all phrase for CLR primitive or any other value type or System.String; not simple type as understood by C# spec

  2. We could implement a workaround using Has.All.Matches but this is not the direction we want to go
